10inch Mid Range Speaker

  • Price:

    Negotiable

  • minimum:

  • Total supply:

  • Delivery term:

    The date of payment from buyers deliver within days

  • seat:

    Zhejiang

  • Validity to:

    Long-term effective

  • Last update:

    2019-02-12 05:06

  • Browse the number:

    295

Send an inquiries

Company Profile

Hangzhou YouYu Trading Co.,Ltd

By certification [File Integrity]

Contact:hzyouyu(Mr.)

Email:

Telephone:

Phone:

Area:Zhejiang

Address:Zhejiang

Website:http://www.chinasoundspeaker.com/ http://hzyouyu.sunla-tech.com/

Product Details


Features

3-inch,fibreglass inside-outside AL voice coil

700 Watt continuous program power handling

98 dB Sensitivity

65-3500 Hz Frequency range


Specification

Nominal diameter  250 mm/10 in

Power rating       350W(AES)

Nominal impedance  8OHM

Sensitivity           98 d B

Frequency range      65-3500 Hz

Magnet weight  78 oz

Voice coil diameter  75.5 mm/3 in


Design

Coil material  AL

Former material  Glass fiber

Cone material  Paper

Surround material  Cloth

Suspension  single

Kind of layers  outside/inside

Number of layers 2

Gap depth  10.0 mm/0.39 in

Voice coil winding width  12 mm/0.47 in


1: 2 hours test made with continuous pink noise signal within the range Fs-10Fs. Power calculated 2: on rated nominal impedance. Loudspeaker in free air.

3:Power on Continuous Program is defined as 3 dB greater than the Nominal rating.

4:Applied RMS Voltage is set to 2.83 V for 8 ohms Nominal Impedance.
